--- title: Slurry Flow Simluation with 3D Computational Fluid Dynamics Modelling description: The team at BBA is doing some great work with this Slurry Flow Simulation. Based on a 3D CFD model using ANSYS CFX. which reduces maintenance costs image: https://blog.soluroc.com/hubfs/Imported%20sitepage%20images/Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_6.jpg --- - Email: sales@soluroc.com - - - [![CWT](https://blog.soluroc.com/hubfs/Soluroc%20Logo.png)](https://soluroc.com) [![Compugen](https://blog.soluroc.com/hubfs/Soluroc%20Logo.png)](https://compugen-8318750.hs-sites.com/it-service-delivery) - [About us](https://soluroc.com/en/about-us/) - [Materials](https://soluroc.com/en/materials/) - Brands & Solutions - [Abreco](https://soluroc.com/abreco/) - [Flexarmor](https://soluroc.com/flexarmor/) - [Fuller](https://soluroc.com/en/fuller-english/) - [Steelguard](https://soluroc.com/steelguard/) - [Moulage de Caoutchouc OEM](https://soluroc.com/moulage-de-caoutchouc-oem/) - [Fonderie](https://soluroc.com/fonderie/) - [Our Team](https://soluroc.com/en/our-team/) - [News & Resources](https://blog.soluroc.com/) - EN # Slurry Flow Simluation with 3D Computational Fluid Dynamics Modelling Canadian Wear Technologies ![Slurry Flow Feed Box Diagram](https://blog.soluroc.com/hubfs/Imported%20sitepage%20images/Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_6.jpg) Our good friends at BBA are doing some great work. Slurry flow is a common means of transporting solid particles in the mining and mineral processing industry. Depending on the slurry mixture, the flow can be very erosive and, at times, maintaining the piping system can be quite challenging. On the other hand, due to the complexity of flow characteristics, it is very difficult to accurately predict slurry flow performance and its erosion rate by only using manual calculation or imperial methods. This paper presents a methodology to simulate the slurry flow in a feed box that is designed to reduce the maintenance associated with the slurry flow, based on a 3D CFD model using ANSYS CFX. In this configuration, the slurry enters the feed box through the inlet pipe, it then fills the first depositing area and, when full, will overflow to the second depositing area before exiting through the outlet pipe (see Figure 1).  The main focus of the simulation is to predict the wall surface where the slurry flow will impact and cause material erosion. Then, lining pads are installed at those specific locations to prevent the feed box from material loss, which reduces maintenance costs and downtime. ![Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_1](https://blog.soluroc.com/hs-fs/hubfs/Imported%20sitepage%20images/Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_1.jpg?width=360&height=363&name=Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_1.jpg) **Figure 1: General geometry** - Model geometry created in SolidWorks and imported to ANSYS - Multi-zone meshing technology (see Figure 2) is applied, which generates high-quality hex-dominant mesh - Average skewness was kept below 0.1 (0 represents the perfect condition) and average orthogonal quality was maintained > 0.9 (1 represents the perfect condition) to improve convergence [![Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_2](https://blog.soluroc.com/hs-fs/hubfs/Imported%20sitepage%20images/Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_2.jpg?width=338&height=314&name=Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_2.jpg)](https://s3.ca-central-1.amazonaws.com/medias.bba.ca/images/Publications/Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_2.jpg) **Figure 2: Model mesh** ## Model assumptions and methodology This model is a three-phase Eulerian-Eulerian model with solid particles, water and air defined individually with different velocity fields: - Continuous water phase - Continuous air phase - Disperse solid phase - In-homogeneous flow and turbulence is set for three phases - Each phase is coupled with two other phases through interfacial drag - A generic yield stress and power-law model\[1\] is used for the slurry flow rheology The variable slurry mixture viscosity is defined as follows: - Set phasic viscosities separately so the mixture viscosity is given by the chosen correlation: μ3r3 + μLrL = μM - Liquid-phase viscosity (μL) is set to be of water - The solid-phase (sand) viscosity (μ3) is a variable that will change based on its volume of fraction This model uses a velocity inlet (gravity fed) and pressure out combination for boundary conditions for smoother convergence. ## Model results [![Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_3](https://blog.soluroc.com/hs-fs/hubfs/Imported%20sitepage%20images/Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_3.png?width=703&height=318&name=Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_3.png)](https://www.bba.ca/wp-content/uploads/2020/02/figureslurryflow-3-4-en.png) [![Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_4](https://blog.soluroc.com/hs-fs/hubfs/Imported%20sitepage%20images/Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_4.png?width=707&height=288&name=Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_4.png)](https://www.bba.ca/wp-content/uploads/2020/02/imagecorrigeeen-blogslurryflow.png)   ## Model validation For general model validation methodology, please refer to article “Optimizing the Design of Penstock Manifolds with 3D Computational Fluid Dynamics (CFD) Simulation”\[2\] In addition, some specific sensitivity cases are created for this application: - 60% solid volume case (see Figure 7) - Two-phase (air and slurry mix) modelling with equivalent slurry mix viscosity [![Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_5](https://blog.soluroc.com/hs-fs/hubfs/Imported%20sitepage%20images/Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_5.jpg?width=730&height=408&name=Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_5.jpg)](https://www.bba.ca/wp-content/uploads/2020/02/figure7-slurryflow.jpg) **Figure 7: Sensitivity case comparison (80% solid volume (left) vs. 60% solid volume (right))** ## Conclusion Figure 8 shows the feed box condition after 3-month’s operation. From the initial observation, the erosion condition seems to align very well with the model prediction. A detailed inspection can be performed at a later date (maybe after a year of operation) to obtain more information to validate model outputs. [![Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_6](https://blog.soluroc.com/hs-fs/hubfs/Imported%20sitepage%20images/Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_6.jpg?width=493&height=370&name=Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_6.jpg)](https://www.bba.ca/wp-content/uploads/2020/02/photo-slurryflow.jpg) **Figure 8: Mineral deposing area** The above reveals a CFD modelling technique that simulates the slurry flow. This methodology can provide reliable and detailed information regarding flow characteristics and performance. It can be of great help for engineers when working on an innovative design for a complex problem. ***References:*** \[1\]        Mueller, S., et al, “The Rheology of Suspensions of Solid Particles”, Proc. R. Soc. A, 466, pp.1201-1228, 2010 \[2\].       Eric Chen, “Optimizing the Design of Penstock Manifolds with 3D Computational Fluid Dynamics (CFD) Simulation”, BBA Publication, BBA, 2019 --- *This blog article originally appeard on [BBA.ca](https://www.bba.ca/publication/slurry-flow-simulation-with-3d-computational-fluid-dynamics-cfd-modelling/) and was written by Kerem Karakok, P.Eng., Ph.D. in colaboration with Eric Chen* *This content is for general information purposes only. All rights reserved ©BBA* ## [Previous post Case Study: Gyratory Crusher Updates Provides $800K Annual Savings](https://blog.soluroc.com/case-study-gyratory-crusher-updates-net-800k-annual-savings) ## [Next post Debottlenecking Mining Operations](https://blog.soluroc.com/debottlenecking-mining-operations) ## Related Post [View more ![](https://blog.soluroc.com/hubfs/mini-right-arrow.svg)](https://blog.soluroc.com) ## [![](https://blog.soluroc.com/hubfs/FULLER%20AND%20SOL.png) Soluroc Acquires Fuller Industrial – Press Release SOLUROC acquires FULLER INDUSTRIAL expanding its position as the Canadian leader in wear-resistant solutions Canadian Wear Technologies July 18, 2025 ![](https://blog.soluroc.com/hubfs/comment-ico.svg)0](https://blog.soluroc.com/soluroc-acquires-fuller-industrial-press-release) ## [![](https://blog.soluroc.com/hubfs/SOLUROC_Logo_Horizontal_Couleur_CMJN.jpg) Soluroc pursues its growth plan LA GUADELOUPE, QC, June 21, 2023 /CNW/ - The Soluroc team is very happy with the evolution of its growth plan and the launch of its new corporate brand. Soluroc intends to become the leader in... Canadian Wear Technologies July 04, 2023 ![](https://blog.soluroc.com/hubfs/comment-ico.svg)0](https://blog.soluroc.com/soluroc-pursues-its-growth-plan) ## [![](https://blog.soluroc.com/hubfs/Figure%203%20-%20Abreco%20Wear%20System.png) Case Study: Gyratory Crusher Updates Provides $800K Annual Savings Summary: Soluroc was approached to address operational efficiencies with a 60 x 89 Allis Chalmers Gyratory Crusher. The Problem: The hard rock mining company was reporting continuous downtime, lost... Canadian Wear Technologies August 13, 2020 ![](https://blog.soluroc.com/hubfs/comment-ico.svg)0](https://blog.soluroc.com/case-study-gyratory-crusher-updates-net-800k-annual-savings) CONNECT ## Need some help? Questions about our brands? Please contact us! [Get In Touch](https://soluroc.com/contact/) ![bg-section](https://blog.soluroc.com/hubfs/bg-section.png) ![logo](https://soluroc.com/wp-content/uploads/2023/05/footer-logo.svg) --- Nos marques - [![Abreco Logo](https://sp-ao.shortpixel.ai/client/to_webp,q_glossy,ret_img,w_1920,h_641/https://soluroc.com/wp-content/uploads/2024/07/ABRECO_Logo_FR_Horizontal_Descripteur_Couleur_Inverse_Alt_RVB.png)](https://blog.soluroc.com/abreco/) - [![Flexarmor Logo](https://sp-ao.shortpixel.ai/client/to_webp,q_glossy,ret_img,w_1920,h_637/https://soluroc.com/wp-content/uploads/2024/07/FLEXARMOR_Logo_FR_Horizontal_Descripteur_Couleur_Inverse_Alt_RVB.png)](https://blog.soluroc.com/flexarmor/) - [![New Brand Logo](https://blog.soluroc.com/hubfs/FULLER_Logo_Horizontal_Descriptor_EN_Colour_Reverse-1920x601-1.png)](https://blog.soluroc.com/fuller/) - [![Steelguard Logo](https://sp-ao.shortpixel.ai/client/to_webp,q_glossy,ret_img,w_1920,h_603/https://soluroc.com/wp-content/uploads/2024/07/STEELGUARD_Logo_FR_Horizontal_Descripteur_Couleur_Inverse_Alt_RVB-1.png)](https://blog.soluroc.com/steelguard/) - © mai 2, 2025 Soluroc - Tous droits réservés - [Termes et Conditions](https://blog.soluroc.com/termes-et-conditions/) - [Politique de confidentialité](https://blog.soluroc.com/politique-de-confidentialite/) ```json { "@context" : "https://schema.org", "@type" : "BlogPosting", "author" : { "@type" : "Person", "name" : "Canadian Wear Technologies", "url" : "https://blog.soluroc.com/author/canadian-wear-technologies" }, "dateModified" : "2023-03-30T14:03:33.630Z", "datePublished" : "2020-08-20T16:35:00.000Z", "headline" : "Slurry Flow Simluation with 3D Computational Fluid Dynamics Modelling", "image" : [ "https://blog.soluroc.com/hubfs/Imported%20sitepage%20images/Blog-Body-Image-KKarakoc-Slurry-simulation-3D-CFD_EN_6.jpg" ], "mainEntityOfPage" : { "@id" : "https://blog.soluroc.com/slurry-flow-simluation-with-3d-computational-fluid-dynamics-cfd-modelling", "@type" : "WebPage" }, "publisher" : { "@type" : "Organization", "logo" : { "@type" : "ImageObject", "url" : "https://blog.soluroc.com/hubfs/Soluroc-logo-white-1.svg" }, "name" : "Soluroc" } } ```
